12 Litre Cross Beam Fruit Press

All prices include VAT
In stock

Looking for a durable and reliable cross beam fruit press? Our 12 litre cross beam press is the perfect choice!

Made from cast iron and sustainably sourced beechwood, this press is built to last a lifetime. The cross beam fruit press comes fully assembled with:

  • Full instructions
  • A tub of lubricating grease
  • A starter juice and cider making guide, making it easy to get started on your homemade creations.

The cross beam design allows for added utility and the pressing plate ensures gentle but consistent pressure, resulting in maximum flavour and nutrient extraction.

We would recommend adding a straining bag (not included) to gather unwanted debris and residue when pressing - available here.

Please note that apples must be crushed into a pomace before pressing, and we recommend checking out our 'How To Crush Apples' and 'Crushers and Mills' sections for further information.

Plus, with a comprehensive 2-year warranty, you can trust in the quality of our product. Order your 12 litre cross beam fruit press today and start making delicious homemade juices and ciders.

Swing the cross beam off the press. Line the press cage with a straining bag (optional; available separately) overlapping the side of the press.  If using Crusher A or the Economy Crusher (available separately) to mill the apples, locate the crusher on top, mill the apples directly into the press until it is brimful, and remove the crusher.  If using the Pulpmaster to mill your apples, swing the cross beam off the press and fill the press cage with crushed fruit.

Fold the edges of the press bag to cover the pomace making a parcel.  Swing the pressure plate over the press cage and crushed fruit and use the butterfly nut to secure in place.  Turn the pressing bar, which will steadily lower the pressure plate.  The juice will soon flow down through the press staves into the plate gully, ready for collection.   Collect the juice in a food-grade bucket, ready for freezing, pasteurisation or irresistible instant drinking.

  •  Cast iron cross beam with threaded spindle and seasoned beech press plate attached – swing away to place a crusher on top.
  • Robust cast iron base plate with lip supported on strong cast iron legs ensures stability of the press when the crossbeam swings to one side.
  • Cast iron legs can be bolted to a table
  • Tough British made food-grade polyester coating
  • The press cage holds 11 kg (24 lbs) of crushed fruit.
  • Press cage made from sustainable beech staves girded by iron hoops
  • Basic Cider & Juice Making booklet by Alex Hill
  • A free tub of food grade grease is supplied with this press
  • Height: 57cm / 22½ "
  • Cage diameter: 28cm / 11"
  • Overall diameter: 43cm / 17"
  • Weight: 32 kg / 70½ lbs

Easy to clean, simply hose down with fresh water after use and dry with a clean cloth. Lubricate the non-food contact metal parts with food grade grease; this will also inhibit corrosion of these parts. Store in a clean, dry place.
